Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
(Bit values = 0: Not Available, 1: Available)
Offset Name Field Bit Description
400h BASIC_FUNC_INQ
Advanced_Feature_Inq [0]
Inquiry for advanced feature.
(Vendor Unique Features)
Vmode_Error_Status_Inq [1]
Inquiry for existence of Vmode_Error_Status
register
Feature_Control_Error_Status_Inq [2]
Inquiry for existence of Feature_Control_Error_
Status register
Opt_Func_CSR_Inq [3] Inquiry for optional function CSR.
[4-7] Reserved
1394.b_mode_Capability [8] Inquiry for 1394.b mode capability
[9-15] Reserved
Cam_Power_Cntl [16] Camera process power ON/OFF capability
[17-18] Reserved
One_Shot_Inq [19] One shot transmission capability
Multi_Shot_Inq [20] Multi shot transmission capability
Retransmit_Inq [21]
Retransmit latest image capability (One_
shot/Retransmit)
Image_Buffer_Inq [22]
Image buffer capability
(Multi_shot/Image_Buffer)
[23-27] Reserved
Memory_Channel [28-31]
Maximum memory channel number (N)
Memory channel
0 = Factory setting memory
1 = Memory Ch 1
2 = Memory Ch 2
:
N= Memory Ch N
If 0000, user memory is not available.
Format:
A.2.2 Feature Presence Inquiry Registers
The following registers show the presence of the camera features or optional functions implemented on the camera.
(Bit values = 0: Not Available, 1: Available)
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
134
