Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
Offset Name Field Bit Description
404h Feature_Hi_Inq
Brightness [0] Brightness Control
Auto_Exposure [1] Auto Exposure Control
Sharpness [2] Sharpness Control
White_Balance [3] White Balance Control
Hue [4] Hue Control
Saturation [5] Saturation Control
Gamma [6] Gamma Control
Shutter [7] Shutter Speed Control
Gain [8] Gain Control
Iris [9] IRIS Control
Focus [10] Focus Control
Temperature [11] Temperature Control
Trigger [12] Trigger Control
Trigger_Delay [13 Trigger Delay Control
White_Shading [14] White Shading Compensation Control
Frame_Rate [15] Frame rate prioritize control
[16-31] Reserved
408h Feature_Lo_Inq
Zoom [0] Zoom Control
Pan [1] Pan Control
Tilt [2] Tilt Control
Optical Filter [3] Optical Filter Control
[4-15] Reserved
Capture_Size [16] Capture image size for Format_6
Capture_Quality [17] Capture image quality for Format_6
[18-31] Reserved
40Ch Opt_Function_Inq
- [0] Reserved
PIO [1] Parallel input/output control
SIO [2] Serial Input/output control
Strobe_Output [3] Strobe signal output
Lookup_Table [4] Lookup table control
- [5-31] Reserved
410h-47Fh Reserved
480h Advanced_Feature_Inq
Advanced_
Feature_Quadlet_
Offset
[0-31]
32-bit offset of the advanced feature CSRs (see the
Advanced Registers section) from the base address of
initial register space. (Vendor unique)
