Point Grey Flea3 FL3-U3 - Feature Elements Inquiry Registers

Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
Offset Name Field Bit Description
484h PIO_Control_CSR_Inq
PIO_Control_
Quadlet_Offset
[0-31]
32-bit offset of the PIO control CSRs (see the Parallel
Input/Output (PIO) section) from the base address of
initial register space.
488h SIO_Control_CSR_Inq
SIO_Control_
Quadlet_Offset
[0-31]
32-bit offset of the SIO control CSRs (see the Serial
Port Input/Output (SIO) section) from the base address
of initial register space.
48Ch Strobe_Output_CSR_Inq
Strobe_Output_
Quadlet_Offset
[0-31]
32-bit offset of the strobe output signal CSRs (see the
Strobe Signal Output section) from the base address of
initial register space.
490h Lookup_Table_CSR_Inq
Lookup_Table_
Quadlet_Offset
[0-31]
32-bit offset of the Lookup Table CSRs from the baes
address of initial register space.
A.2.3 Feature Elements Inquiry Registers
The following registers show the presence of specific features, modes and minimum and maximum values for each of
the camera features or optional functions implemented by the camera.
(Bit values = 0: Not Available, 1: Available)
Offset Name Field Bit Description
500h BRIGHTNESS_INQ
Presence_Inq [0] Presence of this feature
Abs_Control_Inq [1] Absolute value control
[2] Reserved
One_Push_Inq [3]
One push mode (controlled automatically only
once)
ReadOut_Inq [4] Ability to read the value of this feature
On_Off_Inq [5] Ability to switch feature ON and OFF
Auto_Inq [6] Auto mode (controlled automatically)
Manual_Inq [7] Manual mode (controlled by user)
Min_Value [8-19] Minimum value for this feature control
Max_Value [20-31] Maximum value for this feature control
504h AUTO_EXPOSURE_INQ Same format as the BRIGHTNESS_INQ register
508h SHARPNESS_INQ Same format as the BRIGHTNESS_INQ register
50Ch WHITE_BALANCE_INQ Same format as the BRIGHTNESS_INQ register
510h HUE_INQ Same format as the BRIGHTNESS_INQ register
514h SATURATION_INQ Same format as the BRIGHTNESS_INQ register
518h GAMMA_INQ Same format as the BRIGHTNESS_INQ register
51Ch SHUTTER_INQ Same format as the BRIGHTNESS_INQ register
520h GAIN_INQ Same format as the BRIGHTNESS_INQ register
524h IRIS_INQ Same format as the BRIGHTNESS_INQ register
528h FOCUS_INQ Same format as the BRIGHTNESS_INQ register
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
136
