Point Grey Flea3 USB 3.0 Technical Reference 3 General Camera Operation
3.2.3 SENSOR_BOARD_INFO: 1F28h
The interpretation of this register varies depending on the camera type, as
defined in the MAIN_ BOARD_INFO register 0x1F24 (page 30) . Read MAIN_
BOARD_INFO to determine how to use the Sensor_Type_x fields.
Field Bit Description
Sensor_Type_1 [0-11] tbd
Minor_Board_Rev [12-15] Internal use
Reserved [16-27] Reserved
Sensor_Type_2 [28-31] tbd
Format:
3.2.4 VOLTAGE: 1A50h – 1A54h
Offset Name Field Bit Description
1A50h VOLTAGE_LO_INQ
Presence_Inq [0]
Presence of this feature
0: Not available, 1: Available
- [1-7] Reserved
[8-19] Number of voltage registers supported
- [20-31] Reserved
1A54h VOLTAGE_HI_INQ [0-31]
32-bit offset of the voltage CSRs, which report the current voltage
in Volts using the 32-bit floating-point IEEE/REAL*4 format.
Format:
3.2.5 CURRENT: 1A58h – 1A5Ch
Offset Name Field Bit Description
1A58h
CURRENT_
LO_INQ
Presence_
Inq
[0]
Presence of this feature
0: Not available, 1: Available
[1-7] Reserved
[8-19] Number of current registers supported
[20-31] Reserved
1A5Ch
CURRENT_
HI_INQ
[0-31]
32-bit offset of the current registers, which report the current in amps using
the 32-bit floating-point IEEE/REAL*4 format.
Format:
Revised 9/27/2012
