Point Grey Flea3 USB 3.0 Technical Reference 3 General Camera Operation
Main Board Information—This specifies the type of camera (according to the main printed circuit board).
Sensor Board Information—This specifies the type of imaging sensor used by the camera.
Voltage—This allows the user to access and monitor the input as well as several of the internal voltages of the
cameras.
Current—This allows the user to access and monitor the current consumption of the camera.
Temperature—Allows the user to get the temperature of the camera board-level components. For cameras housed
in a case, it is the ambient temperature within the case. For more information about camera temperature, see Case
Temperature and Heat Dissipation on page 18.
Camera Power—Allows the user to power up or power down the camera.
Pixel Clock Frequency—This specifies the current pixel clock frequency (in Hz) in IEEE-754 32-bit floating point format.
The camera pixel clock defines an upper limit to the rate at which pixels can be read off the image sensor.
Horizontal Line Frequency—This specifies the current horizontal line frequency in Hz in IEEE-754 32-bit floating point
format.
3.2.1 SERIAL_NUMBER: 1F20h
Field Bit Description
Serial_Number [0-31] Unique serial number of camera (read-only)
Format:
3.2.2 MAIN_BOARD_INFO: 1F24h
Field Bit Description
Major_Board_Design [0-11]
0x6: Ladybug Head
0x7: Ladybug Base Unit
0x10: Flea
0x18: Dragonfly2
0x19: Flea2
0x1A: Firefly MV
0x1C: Bumblebee2
0x1F:Grasshopper
0x22: Grasshopper2
0x21: Flea2G-13S2
0x24: Flea2G-50S5
0x26: Chameleon
0x27: Grasshopper Express
0x29: Flea3 FireWire 14S3/20S4
0x2A: Flea3 FireWire 03S3
0x2B: Flea3 FireWire 03S1
0x2F: Flea3 GigE 14S3/20S4
0x32: Flea3 GigE 13S2
0x34: Flea3 USB 3.0
0x36: Zebra2
0x39: Flea3 GigE 03S2/08S2
0x3E: Flea3 GigE 50S5
0x3F: Flea3 GigE28S4
0x40: Flea3 GigE03S1
Minor_Board_Rev [12-15] Internal use
Reserved [16-31] Reserved
Format:
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
30
