Point Grey Flea3 USB 3.0 Technical Reference 5 Video Formats, Modes and Frame Rates
Table 5.5: FL3-U3-13E4C Custom Formats, Modes and Frame Rates
Pixel Format 1280 x 1024 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono, Raw) 40 43 124 234 419
12-bit (Mono, Raw, YUV411) 26 28 114 234 419
16-bit (Mono, Raw, YUV422) 20 21 86 234 419
24-bit (YUV444, RGB) 13 14 57 229 419
Mode 0
Pixel Format 640 x 512 640 x 480 320 x 240 160 x 120
8-, 12-, 16-bit (Mono, Raw, YUV411, YUV422) 60 60 60 60
24-bit (YUV444, RGB) 53 57 60 60
Mode 1
Pixel Format 640 x 512 640 x 480 320 x 240 160 x 120
8-bit (Mono, Raw) 119 119 119 119
12-bit (Mono, Raw, YUV411) 108 114 119 119
16-bit (Mono, Raw, YUV422) 81 86 119 119
24-bit (YUV444, RGB) 53 57 119 119
Mode 2
Pixel Format 1280 x 1024 1280 x 960 640 x 480 320 x 240 160 x 120
8-bit (Mono, Raw) 40 43 60 60 60
12-bit (Mono, Raw, YUV411) 26 28 60 60 60
16-bit (Mono, Raw, YUV422) 20 21 60 60 60
24-bit (YUV444, RGB) 13 14 57 60 60
Mode 7
5.3.4 FL3-U3-32S2 Video Modes
5.3.4.1 FL3-U3-32S2 Standard Formats, Modes and Frame Rates
Models: •32S2M • 32S2C
Modes 1.875 FPS 3.75 FPS 7.5 FPS 15 FPS 30 FPS 60 FPS
1600 x 1200 YUV422
• • • • • (default)
1600 x 1200 RGB8
• • • •
1600 x 1200 Y8
•• •• • • •• • (default)• ••
1600 x 1200 Y16
•• •• •• ••
