Additional binning information can be obtained by reading the FORMAT_7_RESIZE_INQ (page 144) register 0x1AC8.
The implementation of Format 7 modes and the frame rates that are possible are not specified by the IIDC, and are
subject to change across firmware versions.
For information about configuring the camera in Format 7 mode, see Video Format, Mode, and Frame Rate Settings
on page 76.
For information about configuring Format 7 modes/sizes and Format 7-related inquiry registers, see Supported
Formats, Modes and Frame Rates on page 69.
When operating in Format 7 mode, the Feature_Lo_Inq register 408h reports the
presence of the Pan and Tilt features. However, these feature are off and cannot
be turned on.
Pixel correction (page 127) is not done in any of the binning modes.
5.1.1 Video Mode Descriptions
Mode Models Description Frame Rate Increase
Brightness
Increase
SNR
Improved
0 All ROI No No No
1
FL3-U3-13S2M
FL3-U3-13E4M
FL3-U3-32S2M
2X/2X
Additive Binning
No Yes No
FL3-U3-13E4C Yes Yes No
FL3-U3-13Y3M
2X/2X
Subsampling
Yes No No
2
FL3-U3-13E4C
FL3-U3-13E4M
2X/2X Subsampling Yes No No
4
FL3-U3-13S2C
FL3-U3-32S2C
FL3-U3-88S2C
2X/2X
On sensor Binning
No Yes Yes
7
FL3-U3-13S2C
FL3-U3-13S2M
FL3-U3-32S2C
FL3-U3-32S2M
Output 12 bits
Extended shutter
No No No
FL3-U3-13E4C
FL3-U3-13E4M
Rolling Shutter No No Yes
8
FL3-U3-13S2C
FL3-U3-13S2M
FL3-U3-32S2C
FL3-U3-32S2M
Smaller fields at faster frame rate No No No
10 FL3-U3-88S2C 4000 x 3000 (12 MP) resolution at 15 FPS No No No
