Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
A.1.2.2 Unit Directory
Offset Bit Description
0000h
[0-15] 0003h
[16-31] CRC
0004h
[0-7] 12h
[8-31] unit_spec_ID (=0x00A02D)
0008h
[0-7] 13h
[8-31] unit_sw_version (=0x000102)
000Ch
[0-7] D4h
[8-31] unit dependent directory offset
A.1.2.3 Unit Dependent Info
Offset Bit Description
0000h
[0-15] unit_dep_info_length
[16-31] CRC
0004h
[0-7] 40h
[8-31]
command_regs_base
32-bit offset from the base address of initial register space of the base address of the command registers
0008h
[0-7] 81h
[8-31]
vendor_name_leaf
The number of 32-bits from the address of the vendor_name_leaf entry to the address of the vendor_
name leaf containing an ASCII representation of the vendor name of this node
000Ch
[0-7] 82h
[8-31]
model_name_leaf
The number of 32-bits from the address of the model_name_leaf entry to the address of the model_
name leaf containing an ASCII representation of the model name of this node
0010h
[0-7] 38h
[8-31]
unit_sub_sw_version
the sub version information of this unit
unit_sub_sw_version = 0x000000h or unspecified for IIDC v1.30
unit_sub_sw_version = 0x000010h for IIDC v1.31
unit_sub_sw_version = 0x000020h for IIDC v1.32
0014h
[0-7] 39h
[8-31] Reserved
0018h
[0-7] 3Ah
[8-31] Reserved
001Ch
[0-7] 3Bh
[8-31] Reserved
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
132
