Point Grey Flea3 USB 3.0 Technical Reference Appendix A: Control and Status Registers
Offset Name Field Bit Description
180h
V_MODE_INQ_O
(Format 0)
Mode_0 [0] 160 x 120 YUV(4:4:4) Mode (24 bits/pixel)
Mode_1 [1] 320 x 240 YUV(4:2:2) Mode (16 bits/pixel)
Mode_2 [2] 640 x 480 YUV(4:1:1) Mode (12 bits/pixel)
Mode_3 [3] 640 x 480 YUV(4:2:2) Mode (16 bits/pixel)
Mode_4 [4] 640 x 480 RGB Mode (24 bits/pixel)
Mode_5 [5] 640 x 480 Y8 (Mono) Mode (8 bits/pixel)
Mode_6 [6] 640 x 480 Y16 (Mono16) Mode (16 bits/pixel)
[7-31] Reserved
184h
V_MODE_INQ_1
(Format 1)
Mode_0 [0] 800 x 600 YUV(4:2:2) Mode (16 bits/pixel)
Mode_1 [1] 800 x 600 RGB Mode (24 bits/pixel)
Mode_2 [2] 800 x 600 Y (Mono) Mode (8 bits/pixel)
Mode_3 [3] 1024 x 768 YUV(4:2:2) Mode (16 bits/pixel)
Mode_4 [4] 1024 x 768 RGB Mode (24 bits/pixel)
Mode_5 [5] 1024 x 768 Y (Mono) Mode (8 bits/pixel)
Mode_6 [6] 800 x 600 Y (Mono16) Mode (16 bits/pixel)
Mode_7 [7] 1024 x 768 Y (Mono16) Mode (16 bits/pixel)
[8-31] Reserved
188h
V_MODE_INQ_2
(Format 2)
Mode_0 [0] 1280 x 960 YUV(4:2:2) Mode (16 bits/pixel)
Mode_1 [1] 1280 x 960 RGB Mode (24 bits/pixel)
Mode_2 [2] 1280 x 960 Y (Mono) Mode (8 bits/pixel)
Mode_3 [3] 1600 x 1200 YUV(4:2:2) Mode (16 bits/pixel)
Mode_4 [4] 1600 x 1200 RGB Mode (24 bits/pixel)
Mode_5 [5] 1600 x 1200 Y (Mono) Mode (8 bits/pixel)
Mode_6 [6] 1280 x 960 Y (Mono16) Mode (16 bits/pixel)
Mode_7 [7] 1600 x 1200 Y (Mono16) Mode (16 bits/pixel)
[8-31] Reserved
18Ch
:
197h
Reserved
Format:
