Point Grey Flea3 USB 3.0 Technical Reference 7 Imaging Parameters and Control
Offset Name Field Bit Description
80008h LUT_Ctrl
Presence_Inq [0]
Presence of this Feature
0: Not Available, 1: Available
[1-4] Reserved
ON_OFF [5]
Read: read a status
Write: ON or OFF this feature
0: OFF 1: ON
When ON is written, the ON_OFF field of the
GAMMA register is turned to OFF.
[6-27] Reserved
Active_Bank [28-31] Active bank
8000Ch
Bank_0_
Offset_Inq
Bank_0_Quadlet_Offset [0-31] 32-bit offset of Bank 0 table data
80010h
Bank_1_
Offset_Inq
Bank_1_Quadlet_Offset [0-31] 32-bit offset of Bank 1 table data
80014h
Bank_2_
Offset_Inq
Bank_2_Quadlet_Offset [0-31] 32-bit offset of Bank 2 table data
80018h
Bank_3_
Offset_Inq
Bank_3_Quadlet_Offset [0-31] 32-bit offset of Bank 3 table data
8001Ch
Bank_4_
Offset_Inq
Bank_4_Quadlet_Offset [0-31] 32-bit offset of Bank 4 table data
80020h
Bank_5_
Offset_Inq
Bank_5_Quadlet_Offset [0-31] 32-bit offset of Bank 5 table data
80024h
Bank_6_
Offset_Inq
Bank_6_Quadlet_Offset [0-31] 32-bit offset of Bank 6 table data
80028h
Bank_7_
Offset_Inq
Bank_7_Quadlet_Offset [0-31] 32-bit offset of Bank 7 table data
8002Ch
Bank_8_
Offset_Inq
Bank_8_Quadlet_Offset [0-31] 32-bit offset of Bank 8 table data
80030h
Bank_9_
Offset_Inq
Bank_9_Quadlet_Offset [0-31] 32-bit offset of Bank 9 table data
80034h
Bank_10_
Offset_Inq
Bank_10_Quadlet_Offset [0-31] 32-bit offset of Bank 10 table data
80038h
Bank_11_
Offset_Inq
Bank_11_Quadlet_Offset [0-31] 32-bit offset of Bank 11 table data
8003Ch
Bank_12_
Offset_Inq
Bank_12_Quadlet_Offset [0-31] 32-bit offset of Bank 12 table data
80040h
Bank_13_
Offset_Inq
Bank_13_Quadlet_Offset [0-31] 32-bit offset of Bank 13 table data
80044h
Bank_14_
Offset_Inq
Bank_14_Quadlet_Offset [0-31] 32-bit offset of Bank 14 table data
80048h
Bank_15_
Offset_Inq
Bank_15_Quadlet_Offset [0-31] 32-bit offset of Bank 15 table data
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
108
