Point Grey Flea3 USB 3.0 Technical Reference 7 Imaging Parameters and Control
Field Bit Description Frame-Specific Information
ROI_Pos_Inq [6]
Presence of image-specific information display
0: Not Available, 1: Available
GPIO_State_Inq [7]
Strobe_Pat_Inq [8]
Frame_Count_Inq [9]
WB_CSR_Inq [10]
Exp_CSR_Inq [11]
Bright_CSR_Inq [12]
Shutter_CSR_Inq [13]
Gain_CSR_Inq [14]
Time_Inq [15]
CSR_Abs_Value [16]
Toggles between displaying 32-bit relative or absolute CSR values. If absolute value not
supported, relative value is displayed.
0: Relative, 1: Absolute
This field is currently read-only
[17-21] Reserved
Insert_Info
[22]
Display image-specific information
0: Off 1: On
Region of Interest (ROI) position (See page 120)
[23] GPIO Pin State
[24] Strobe Pattern Counter
[25] Frame Counter
[26] White Balance CSR
[27] Exposure CSR
[28] Brightness CSR
[29] Shutter Value
[30] Gain CSR
[31] Timestamp (See page 120)
