Point Grey Flea3 USB 3.0 Technical Reference 3 General Camera Operation
Register Name Offset
CURRENT_FRAME_RATE 600h
CURRENT_VIDEO_MODE 604h
CURRENT_VIDEO_FORMAT 608h
CAMERA_POWER 610h
CUR_SAVE_CH 620h
BRIGHTNESS 800h
AUTO_EXPOSURE 804h
SHARPNESS 808h
WHITE_BALANCE 80Ch
HUE 810h
SATURATION 814h
GAMMA 818h
SHUTTER 81Ch
GAIN 820h
IRIS 824h
FOCUS 828h
TRIGGER_MODE 830h
TRIGGER_DELAY 834h
FRAME_RATE 83Ch
PAN 884h
TILT 888h
ABS_VAL_AUTO_EXPOSURE 908h
ABS_VAL_SHUTTER 918h
ABS_VAL_GAIN 928h
ABS_VAL_BRIGHTNESS 938h
ABS_VAL_GAMMA 948h
ABS_VAL_TRIGGER_DELAY 958h
ABS_VAL_FRAME_RATE 968h
IMAGE_DATA_FORMAT 1048h
AUTO_EXPOSURE_RANGE 1088h
AUTO_SHUTTER_RANGE 1098h
AUTO_GAIN_RANGE 10A0h
GPIO_XTRA 1104h
SHUTTER_DELAY 1108h
GPIO_STRPAT_CTRL 110Ch
GPIO_CTRL_PIN_x 1110h, 1120h, 1130h, 1140h
GPIO_XTRA_PIN_x 1114h, 1124h, 1134h, 1144h
Revised 9/27/2012
Copyright ©2011-2012 Point Grey Research Inc.
34
