Polaris 2003 Pro X User Manual

REAR SUSPENSION/TRACK/TRACTION
7.10
Front Track Shock - 440 Pro X Fan -- Ryde FX
P/N 7042205
Walker Evans Racing Shock -- PN 7042205
Shock Design Details (Inches)
Travel 3.74...............
Extended Length 11.98.....
Compressed Length 8.24..
IFP Depth N/A...........
Nitrogen 300 psi............
Oil Capacity 100--110 cc.........
Hose Length N/A.........
Piston (orifice .086)
Lock nut
.700x.010
.800x.010
.900x.010
1.000x.010
1.100x.010
1.250x.010
Compression
Rebound
Shaft
End
Nut
End
Valving
Stack shown as placed on the
shock rod with rod in a vice.
PISTON ORIENTATION
1.300x.008
.900x.008
1.250x.008
1.000x.008
.900x.010
.800x.010
Shaft End
Nut
End
Valving
Stack shown as placed on the
shock rod with rod in a vice.
PISTON ORIENTATION
