ENGINE
3
Engine Sensors & Misc. Exploded View






84  4 in.lbs.
(9.5  0.9 Nm)
20  5 in.lbs.
(2.5  0.55 Nm)
18  2 ft.lbs.
(24.5  2.7 Nm)
20  5 in.lbs.
(2.5  0.55 Nm)
84  4 in.lbs.
(9.5  0.9 Nm)
25  3 ft.lbs.
(34  0.14 Nm)
84  4 in.lbs.
(9.5  0.9 Nm)
18  2 ft.lbs.
(24.5  2.7 Nm)
A. Screws
B. Rocker Cover
C. Breather
D. O-ring Seal
E. Breather Bolts
F. Spark Plugs
G. Carburetor Boot
H. Bolts
I. Boot Clamp
J. Throttle Body
K. Crank Position Sensor
L. Thermistor
M. O-ring
N. Thermostat Housing
O. Bolts
P. Gasket
Q. Exhaust Manifold
R. Bolts
S. Thermostat
A
B
E
C
D
F
(Apply Dielectric Grease
to threads of Spark Plug)
G
H
I
J
Apply Corrosion
Resistant Grease
K
L
M
NO
P
Q
18  2 ft.lbs.
(24.5  2.7 Nm)
R
