3.41
ENGINE
3
33. Place the shaft in a press to remove the bearing.
34. Press shaft into the new bearing..
35. Press the bearing/shaft assembly using the bearing's outer
race. Do not use the shaft to press the assembly into the
housing, as bearing damage may result. Install retaining
ring.
36. Press gear onto shaft while supporting the housing.
37. Remove thrust plate (U).
38. Remove PTO end engine mount Remove crankcase bolts.
Tap on the reinforced areas on the cases using soft hammer.
Carefully separate the two crankcase halves.
Bearing
New Bearing
Press Bearing/Shaft
Assembly using
outer race only
U
Separate
Crankcase Halves
To Next Page
