Polaris 600 RUSH 2010 User Manual

9.3
Chassis
9
SPECIFICATIONS
Fastener Torque Specifications
COMPONENT TORQUE
Rear hood-to-rear over
structure screws
7.4 ft-lbs (10 Nm)
Head light asm.front/air box
screw
s
3 ft-lbs (4 Nm)
Head light asm. side
mo
unting screws
7.4 ft-lbs (10 Nm)
Front bumper-to-over
stru
cture/heat exchanger
fasteners
7.4 ft-lbs (10 Nm)
Seat screws 7.4 ft-lbs (10 Nm)
Seat brace-to-x brace
screw
s
7.4 ft-lbs (10 Nm)
Seat brace-to-rear brace
screw
s
17 ft-lbs (23 Nm)
Bulkhead clip fasteners/
nu
ts
26 ft-lbs (35 Nm)
Exhaust silencer fasteners/
nu
ts
26 ft-lbs (35 Nm)
Right side brace fasteners/
nu
ts
26 ft-lbs (35 Nm)
Left side brace fasteners/
nu
ts
26 ft-lbs (35 Nm)
Left side front/rear engine
mount
s-brace fasteners
22 ft-lbs (30 Nm)
Cross brace screws 35 ft-lbs (47 Nm)
Front over structure-to-
b
ulkhead clip fasteners
22 ft-lbs (30 Nm)
Front over structure-to-rear
o
ver structure tube
fasteners
17 ft-lbs (23 Nm)
Rope guide fastener 7 ft-lbs (9.5 Nm)
Rear over structure-to-front
tun
nel mount/x-brace
fastener
35 ft-lbs (47 Nm)
Rear over structure-to-
tun
nel fastener
22 ft-lbs (30 Nm)
X-brace-to-rear brace
sup
port fasteners
35 ft-lbs (47 Nm)
Front footrest tube/rear
over structure fasteners
22 ft-lbs (30 Nm)
Running board support-to-
r
ear support braces
26 ft-lbs (35 Nm)
Rear support brace tunnel
fa
steners
26 ft-lbs (35 Nm)
Bulkhead cooler-to-tunnel/
br
aces fasteners
26 ft-lbs (35 Nm)
COMPONENT TORQUE

Polaris 600 RUSH 2010 Specifications

General

Horsepower	120 HP
Engine Displacement	599 cc
Cylinders	2
Cooling	Liquid
Bore x Stroke	77.25 mm x 64 mm
Fuel System	Cleanfire Injection
Ignition	Digital CDI
Front Suspension	PRO-RIDE
Rear Suspension	PRO-RIDE
Track Width	15 in
Track Lug Height	1.25 in
Front Travel	9 in
Ski Stance	42.5 in
Brake	Hydraulic Disc
Width	48 in
Starter	Electric
Drive Clutch	P-85
Track Length	121 in
Rear Travel	14 in
Ski Type	Gripper
Driven Clutch	TEAM
