Polaris 600 RUSH 2010 User Manual

2.31
Maintenance
2
3. Adjust handlebars to desired position. Verify the
wiring harness, brake hose, and throttle cable do not
kink.
NOTE: Verify “FWD” printed on riser faces front of
s
nowmobile
4. Secure the front clamp fasteners first to specification.
Fin
ish by securing the two rear clamp fasteners to the
same torque setting.
5. Reinstall the handlebar cover
if equipped.
Adjustable Riser
Periodically inspect the torque of the upper/lower
handlebar clamp fasteners, and slide fasteners.
Ski/Ski Skag Fasteners
Periodically inspect the ski-to-spindle fasteners for proper
torque.
Inspect ski skags and skag fasteners for abnormal wear
a
nd tear. Replace skags when carbide edge is worn away
or when skag is bent/damaged.
Always use new lock nuts when replacing parts.
= T
Handlebar Clamp Fastener Torque:
A = 14.7 ft-lbs (20 Nm)
= T
Handlebar Clamp Fastener Torque:
A = 15.4 ft-lbs (21 Nm) Apply Loctite® 243™
ROX Slide Fastener Torque:
B = 15 ft-lbs (20 Nm)
Adjuster Cranks: Hand Tight
A
A
B
= T
A = 36 ft-lbs (50 Nm)
B = 6 ft-lbs (8 Nm)
C = 7 ft-lbs (10 Nm)
D = 9 ft-lbs (12 Nm)
SKI STOP (“FRONT” TO SKI TIP)
SKI LOOP/HANDLE
SKI SKAG/CARBIDE
A
B
C
D

Polaris 600 RUSH 2010 Specifications

General

Horsepower	120 HP
Engine Displacement	599 cc
Cylinders	2
Cooling	Liquid
Bore x Stroke	77.25 mm x 64 mm
Fuel System	Cleanfire Injection
Ignition	Digital CDI
Front Suspension	PRO-RIDE
Rear Suspension	PRO-RIDE
Track Width	15 in
Track Lug Height	1.25 in
Front Travel	9 in
Ski Stance	42.5 in
Brake	Hydraulic Disc
Width	48 in
Starter	Electric
Drive Clutch	P-85
Track Length	121 in
Rear Travel	14 in
Ski Type	Gripper
Driven Clutch	TEAM
