1.8
General Information
2011 800 Switchback Assault
Model Numbers:
800 Switchback Assault 1.3
S11CW8GSA / S11CW8GSB / S11CW8GEA
S11CW8GEB

800 Switchback Assault 2.0
S11CW8GST
NOTE: OPTIONAL - USE 2 GRAM LIGHTER CLUTCH
W
EIGHTS WHEN OPERATING IN PROLONGED
WARM TEMPERATURES (LATE FALL/SPRING
SEASON) TO MAINTAIN PEAK OPERATING RPM.
Engine
Engine Type
Liberty Liquid-Cooled /
Case Reed
Induction
Model Number S4229-8044-OO8G
Displacement / # Cylinders 794cc / 2
Bore (inches/mm) 3.34 / 85
Stroke (inches/mm) 2.75 / 70
Piston to Cylinder
Cle
arance (inches/mm)
.004-.0055 / 0.103-0.141
Installed Ring Gap
(inches / mm)
.017-.025 / 0.450-0.650
Operating RPM +0-300 8250
Idle RPM ±200 1700
Engagement RPM ±200 3800
Exhaust Valve Spring Orange
Thermostat Opening
T
emperature (° F/ ° C)
120 / 49
Fuel Delivery
Type - Number of Fuel
Inj
ectors
DC-CFI - 2
Throttle Body Marking 1204094
Throttle Body Bore 48mm
TPS Voltage @ Idle
(5 VDC +/- .01 Input)
0.94 +/- 0.01 VDC
Fuel Pressure - PSI (bar) 58-60 (4.0-4.1)
Fuel Octane (R+M/2)
10% Ethanol 24 Resistor





Premium/Non-Ethanol
16
0 Resistor
<91 Octane
(Non
-Oxygenated)
OR
87/89/91+
(Up to10% Oxygenated)
91+
(Non-Oxygenated)
800 Switchback Assault 1.3 Clutch Settings
ALTITUDE
meters
(feet)
DRIVE CLUTCH DRIVEN CLUTCH
Shift
W
eight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-66
BLACK
120-310
7043681
BLU/BLK
123-203
7043064
64/42 - .36
5135401
23:39 - 72
600-1200
(2000-4000)
10-64
1200-1800
(4000-6000)
10-62
1800-2400
(6000-8000)
10-60
BLK/PUR
16
0-240
7043363
21:40 - 72
2400-3000
(8000-10,000)
BLACK
14
0-330
7043829
20:42 - 72
3000-3600
(10,000-12,000)
10-58
Drive Clutch Bolt Torque: 80 ft-lbs (108Nm)
Re-torque after running engine.
800 Switchback Assault 2.0 Clutch Settings
ALTITUDE
meters
(feet)
DRIVE CLUTCH DRIVEN CLUTCH
Shift
W
eight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-66
BLACK
120-310
7043681
BLU/BLK
123-203
7043064
64/42 - .36
5135401
20:42 - 72
600-1200
(2000-4000)
10-64
1200-1800
(4000-6000)
10-62
1800-2400
(6000-8000)
10-60
BLK/PUR
16
0-240
7043363
2400-3000
(8000-10,000)
BLACK
14
0-330
7043829
3000-3600
(10,000-12,000)
10-58
Drive Clutch Bolt Torque: 80 ft-lbs (108Nm)
Re-torque after running engine.
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm) 144 (365.76)
Pitch
Plies
2.52
2
Lug Height - Inches (cm) 
1.3
2.0
1.352 (3.43) (Cobra)
2
.0 (5.08) (Series 4)
Track tension sag in/cm
with 10 lbs/4.54kg place
d
16 in/40cm ahead of rear
idler shaft
3/8
- 1/2(1 - 1.3cm)

Polaris 600 RUSH 2010 Specifications

General

Horsepower	120 HP
Engine Displacement	599 cc
Cylinders	2
Cooling	Liquid
Bore x Stroke	77.25 mm x 64 mm
Fuel System	Cleanfire Injection
Ignition	Digital CDI
Front Suspension	PRO-RIDE
Rear Suspension	PRO-RIDE
Track Width	15 in
Track Lug Height	1.25 in
Front Travel	9 in
Ski Stance	42.5 in
Brake	Hydraulic Disc
Width	48 in
Starter	Electric
Drive Clutch	P-85
Track Length	121 in
Rear Travel	14 in
Ski Type	Gripper
Driven Clutch	TEAM
