1.9
General Information
1
General
Width (in/cm) 48 / 121.9
Length (in/cm) 126 / 320
Height (in/cm) 48 / 121.9
Estimated Dry Weight (lb/kg) 457 / 212.7
Fuel (Gallons / Liters) 11.5 / 43.5
Oil (Quarts / Liters) 3.4 / 3.3
Cooling System
Cap
acity(Qts/ L)
6.0/5.7
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211115
1.46
0 / 3.7
26°
46.77 / 118.8
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
7.53
23
39
72
Polaris Sy
nthetic (80W)
9 / 266
PERC
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 VDC (Total)
13.5 - 14.5 VDC
400
Ignition Timing
18° @1700 RPM
Co
olant Temp = 120° F (49° C)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug NGK BPR9ES
Front Suspension
Suspension Type
PRO-RIDE
Shocks
Walker Evans Needle Piggyback
16 Click
Compression
Adjustable
Factory Setting** = 6
IFS Spring Rate
lbs/in (N/mm)
100 (17.5)
IFS Spring Installed
Len
gth - Inches (cm)
10.0 (25.4)
Front Vertical Travel
Inches (cm)
9 (22.9)
Ski Center Distance
Inches (cm)
Setup Width
42.5 (108)
41
.52 (105)
Camber Inches (cm) 1.68 0.31
(4.3 .8)
Toe Out Inches (mm) 0 -1/8
(0 - 3)
Rear Suspension
Suspension Type Switchback 144 Tipped
Front Track Shock
(FTS)
Walker Evans Piggyback
16 C
lick Compression
Adjustable
Factory Setting** = 8
FTS Spring Rate
lbs/in (N/mm)
170 (21 - 54.25)
FTS Spring Installed
Len
gth
Inches (cm)
7.25 (18.4)
Rear Track Shock
(RTS)
Walker Evans
w/
Remote Reservoir
16 Click Compression
Adjustable
Factory Setting** = 8
Torsion Springs
.359/77°
LH
=7041629-329
RH=7041630-329
Rear Travel
Inches (cm)
14.5 (36.8)
