9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
2.5
2. Rotate the spark plug wrench counter-clockwise to
release it from the bracket.
3. Pull the wrench upward to remove it.
4. Tilt the tool kit container until the bracket detaches
from the bumper tube.
5. Pull the container out of the compartment.
6. When reinstalling the drive belt into the container, fold
the belt as shown. Verify that the belt loop at the rear
of the container is positioned slightly higher than the
front loop.
7. Slide the container into the engine compartment at an
angle.
8. Position the container bracket onto the bumper tube
and rotate it downward.
9. Reinstall the spark plug wrench into the bracket and
through the hole in the bumper tube.
10.Rotate the spark plug wrench clockwise until it locks
into place.
MAINTENANCE
