9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
3.63
STATOR / FLYWHEEL SERVICE
FLYWHEEL REMOVAL / INSPECTION
1. Remove the exhaust pipe and silencer. See Exhaust
Removal.
2. If the recoil assembly does not require attention, the
recoil rope can remain attached to the handle. If recoil
component work is desired, reference the Recoil
Assembly section.
3. Remove the recoil/magneto housing cover. The recoil
assembly is located inside the housing.
4. Remove the recoil starter pulley fasteners
q
and
recoil starter pulley
w
from the flywheel.
NOTICE
The recoil fan is balanced and can only be installed on
the flywheel one way because of an asymmetrical hole
pattern.
5. Secure the flywheel using the Flywheel Holding tool
e
. Start by aligning all the mounting holes and install
the two shoulder bolts
e
into the flywheel until they
bottom out. Then install three of the fasteners
r
from
the recoil starter pulley into the crankcase.
Flywheel Holding Tool:
PU-52602
NOTICE
Ensure there is a little play and the flywheel is able to
move freely when all fasteners are installed.
6. Remove the flywheel nut
y
.
7. Remove the Flywheel Holding tool.
ENGINE / COOLING / EXHAUST
