9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
NEXT-GEN SERVICE POWER HARNESS CIRCUIT DIAGRAM
This circuit diagram for the Next-Gen Service Power Harness may be found in the table below. To access the circuit
diagram , select “Click Here” to view the diagram.
In addition to the diagram being available in the online service manual, the circuit diagram may also be found in the
back of the paper manual.
CIRCUIT NOTES
Next-Gen Service Power Harness Circuit: Click
Here.
Used to supply power to the fuel pump prime jumper, chassis
power, instrument cluster power, critical power, and ECU power
circuits when connected to a 12V stand-alone automotive type
battery with the Chassis Power-Up Harness.
BATTERY / ELECTRICAL
