9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
1.63
MISC SPECIFICATIONS AND CHARTS
MASTER TORQUE TABLE
ENGINE FASTENERS
ENGINE
ITEM
TORQUE
Intake Tube Air Box
Fastener
36 in-lbs (4 Nm)
Oil Tank Fastener
7 ft-lbs (9 Nm)
Throttle Cable Lock Nut
44 in-lbs (5 Nm)
Throttle Body Adapter
Plate Gear Clamps
11 in-lbs (1.24 Nm)
Air Box Throttle Body
Gear Clamps
11 in-lbs (1.24 Nm)
Air Box Coil Fasteners
ft-lbs (Nm)
Engine Mount Fasteners 40 ft-lb (54 Nm)
Engine Mount Fasteners
Left Front Mount
26 ft-lbs (35 Nm)
Front MAG Engine Mount
Base Fasteners
22 ft-lb (30 Nm)
Rear MAG Engine Mount
Base Fasteners
26 ft-lbs (35 Nm)
Spark Plug 22 ft-lb (30 Nm)
Cooling Hose Clamp
5 ft-lbs 7 Nm
Coolant Bottle Bracket
Fasteners
7 ft-lbs (9 Nm)
PATRIOT ENGINE TORQUE VALUES
ENGINE
ITEM
TORQUE
Cylinder Head Fasteners
(M8 x 1.25 x 50)
23 ft-lbs (31 N·m)
Spark Plug 22 ft-lbs (30 N·m)
Cylinder Fasteners
(M10 x 1.50 x 83)
40 ft-lbs (54 N·m)
Apply VES oil under
fastener head and to
threads prior to
installation.
Cylinder Fasteners
(M10 x 1.50 x 127)
40 ft-lbs (54 N·m)
Apply VES oil under
fastener head and to
threads prior to
installation.
ENGINE
ITEM
TORQUE
Crankcase Fasteners
(M8 x 1.25 x 50)
24 ft-lbs (32 N·m)
Apply VES oil under
fastener head and to
threads prior to
installation.
Crankcase Fasteners
(M8 x 1.25 x 80)
24 ft-lbs (32 N·m)
Apply VES oil under
fastener head and to
threads prior to
installation.
Stator Fasteners
(M6 x 1.0 x 32)
12 ft-lbs (16 N·m)
Flywheel Flange Nut
(M14 x 1.50)
90 ft-lbs (122 N·m)
CPS Fasteners
(M5 x 0.8 x 10)
53 in-lbs (6 N·m)
Recoil Starter Pulley
Fasteners
10 ft-lbs (13 N·m)
Apply Loctite 262
Recoil Housing Fasteners 9 ft-lbs (12 N·m)
Recoil Friction Plate
Fastener
15 ft-lbs (20 N·m)
Engine Mount Fasteners
(M8 x 1.25 x 20)
18 ft-lbs (24 N·m)
Engine Mount Bracket
Nut
(M8 x 1.25)
18 ft-lbs (24 N·m)
Hold mount in place when
torquing
Water Pump Cover
Fasteners
(M6 x 1.0 x 20)
9 ft-lbs (12 N·m)
Water Pump Driven Shaft
Nut
(M8 x 1.25)
9 ft-lbs (12 N·m)
EV Valve Push / Pull
Cable
9 ft-lbs (12 N·m)
Exhaust Valve Tiebar
Fasteners
(M6 x 1.0 x 16)
14 ft-lbs (19 N·m)
EV Valve Push / Pull
Cable Fastener
(M6 x 1.0 x 12)
9 ft-lbs (12 N·m)
Exhaust Valve Base
Fasteners
(M6 x 1.0 x 30)
9 ft-lbs (12 N·m)
GENERAL INFORMATION
