6.32
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
DRIVESHAFT INSTALLATION
1. From underneath the tunnel, install the track. Verify
the arrows on the track point in the direction of
forward vehicle travel.
2. Insert the driveshaft through the clutch-side of the
bulkhead.
3. Insert the splined-end of the driveshaft into the
chaincase.
4. Verify the bearing cup studs are pushed through the
bulkhead.
5. Install the bearing cover and loosely install the
bearing cover / flangette fasteners.
6. Torque the bearing cover / flangette fasteners to
specification.
TORQUE
Driveshaft Bearing Cover / Flangette Fasteners:
18 ft-lbs (25 Nm)
7. Reinstall the rear suspension.
8. Follow the procedure for chaincase reassembly.
9. Reinstall the driven clutch assembly.
FINAL DRIVE / BRAKE SYSTEMS
