9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
8.25
RMK 174" REAR SUSPENSION PIVOT / BRACE SHAFT ASSEMBLY VIEW
q
Screw
33 ft-lbs (45 Nm)
Apply Loctite 263
s
Washer
2!
Shaft
w
Screw
50 ft-lbs (68 Nm)
Apply Loctite 263
d
Rear Idler Shaft
2@
Bolt
e
Washer
f
Idler Spacer
2#
Rear Pivot
r
Nut
33 ft-lbs (45 Nm)
g
Bushing
2$
Nut
6 ft-lbs (8 Nm)
t
Washer
h
Idler Wheels 2%
Lubrication Fitting
y
Shaft
j
Center Idler Spacer
2^
Shaft
u
Outside Spacer
k
Idler Spacer
2&
Rear Torque Arm Brace
i
Bogie Wheel
l
Washer
2*
Front Torque Arm Brace
o
Inside Spacer
1(
Screw
55 ft-lbs (75 Nm) +/- 10%
2(
Shaft
a
Wave Washer
2)
Screw
STEERING / SUSPENSIONS
