9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
8.15
SPINDLE INSTALLATION
1. Loosely install the spindle onto the upper and lower
control arms using new flange nuts.
Lower Control Arm:
Upper Control Arm:
2. Torque lower control arm and upper control arm
spindle nuts to specification.
TORQUE
Upper / Lower Control Arm Spindle Nuts:
40 ft-lbs (54 Nm)
3. Reinstall the steering tie rod end nut. Verify the
washer is installed under the rod end flange. Torque
new flange nut to specification.
TORQUE
Steering Tie Rod End Spindle Nut:
37 ft-lbs (50 Nm)
4. Reinstall the ski assembly. Verify the washers are
installed dome-side out. Torque new ski flange nut to
specification.
TORQUE
Ski Fastener Flange Nuts:
37 ft-lbs (50 Nm)
STEERING / SUSPENSIONS
