3.14
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
OIL SUPPLY HOSE ROUTING
NOTICE
Images for reference only.
1. From the electronic oil pump, route the oil supply hose up to the oil hose support and secure with a panduit strap
q
.
2. Continue routing the oil supply hose up to the oil tank fitting and secure with clamp
w
.
ENGINE / COOLING / EXHAUST
