3.13
OIL CHECK VALVE FITTING HOSE CLAMP POSITION
When installing a hose clamp on an oil check valve fitting the two wires of the clamp
q
have to be around the center
barb on the fitting
w
.
IMPORTANT
If an oil supply hose falls off of a check valve, the check valve must be pressure tested to ensure it works properly. If
the center crankcase waterpump cross shaft oil supply hose falls off of the check valve, the internal outlet check valve
must be pressure tested.
ENGINE / COOLING / EXHAUST
