LINE FLOW PORT FITTING LINE LENGTH ENGINE FITTING
q
Low (LO) 14.56 in (370 mm) PTO Crank Bearing
w
High (HI) 9.45 in (240 mm) PTO Lower Case Injector
e
Low (LO) 11.02 in (280 mm) CTR Crank Bearing
r
High (HI) 9.45 in (240 mm) MAG Lower Case Injector
t
Low (LO) 9.45 in (240 mm) MAG Crank Bearing
y
Oil Supply Hose
(Connects to Oil Tank)
18.11 in (460 mm)
N/A
IMPORTANT
High (HI) ports connect to Lower Case Injectors ONLY.
NOTICE
Perform Oil Pump Prime procedure in Digital Wrench if engine oil supply lines have air bubbles larger than 1 in (2.54
cm) or the lines are removed / replaced.
