8
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
8.55
REAR SUSPENSION
FRONT TRACK SHOCK (FTS) FACTORY
SPRING SETTINGS
IMPORTANT
Never exceed the minimum/maximum spring preload
settings. Always remove the vehicle weight from the
spring prior to making adjustments.
FACTORY
SPRING
MAXIMUM
INSTALLED
LENGTH
MINIMUM
INSTALLED
LENGTH
PRO-RMK 8.375" (21.3 cm) 8.2" (20.8 cm)
RMK KHAOS 6.5” (16.5 cm) 6.25” (15.9 cm)
SKS 8.375" (21.3 cm) 8.2" (20.8 cm)
FRONT TRACK SHOCK (FTS) FACTORY
CLICKER SETTINGS
To reset FTS clickers, rotate the clicker to full stiff, and
then back off the same number of clicks for each shock.
High Speed Adjustment
Low Speed Adjustment
MODEL
FACTORY CLICKER
SETTING (FROM FULL
STIFF)
RMK KHAOS
Low-Speed: 6
High-Speed: 4
STEERING / SUSPENSIONS
