OIL TANK REMOVAL
1. Remove the side panels and hood.
2. Remove the oil level sender connector
q
.
3. Remove the oil tank mounting fastener
w
and washer
e
.
4. Slide the oil tank forward and tilt it on its side to gain
access to the oil line fitting
5. Slide the springband clamp
r
down the oil line.
6. Remove the oil line
t
from the fitting
y
and quickly
plug the fitting hole.
NOTICE
Place a rag under the fitting to catch any spilled oil.
7. Remove the oil tank
u
.
ENGINE / COOLING / EXHAUST
