9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
4. Remove the throttle block cover screws
y
and cover
u
.
5. Remove the throttle release switch
i
from the
throttle block
o
. Note the orientation of the switch
during removal.
6. Slide the lower block
a
out of the upper block
s
.
Remove the throttle blocks from the handlebar.
TWO PIECE THROTTLE CONTROL
INSTALLATION
1. Reverse removal procedure to assembly throttle
block assembly. Torque fasteners to specifications.
TORQUE
Throttle Cover Screws:
6 in-lbs (0.7 Nm)
Auxiliary Stop Switch Mount Screw:
12 in-lbs (1.4 Nm)
Throttle Block Set Screw:
27 in-lbs (3.1 Nm)
STEERING / SUSPENSIONS
