3.72
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
9. Insert the inner cage assembly
t
into the outer
flange
y
as shown until the locating tabs snap into
their openings. When assembled correctly, the inner
cage should be flush with the outer flange.
10.When installing each reed assembly back into the
engine, verify the model number
A
is at the bottom
and “MOTOTASSINARI”
B
is at the top.
ENGINE / COOLING / EXHAUST
