20.Pinch-off the throttle body coolant hoses using hose
pincher tools.
Hose Pincher:
PU-45149
21.Remove the hoses
l
from the throttle body.
22.Cut the cable ties
1(
that secure the fuel injector
harness to the throttle body.
23.Disconnect the TPS harness connector.
NOTICE
Note the cable tie position and TPS harness routing
prior to disconnecting the TPS.
24.Loosen the two gear clamps
2)
that secure the
throttle body to the throttle body adapter.
25.Pull the throttle body out of the throttle body adapter.
26.Loosen the throttle cable lock nut
2!
and remove the
cable from the throttle body.
27.Remove the throttle body from the vehicle.
