WALKER EVANS PIGGYBACK SHOCK ASSEMBLY VIEW
REF. DESCRIPTION
TORQUE / NOTE
q
Shaft Eyelet 30 ft-lbs (40 Nm)
w
Shock Body
e
Seal Head Assembly 10 ft-lbs (14 Nm)
r
D-Type Wiper Seal Replace with new when servicing shock.
t
U-Cup Seal Replace with new when servicing shock.
y
O-Ring Replace with new when removed.
u
O-Ring Replace with new when servicing shock.
i
Shaft Bushing Replace seal head assembly if shaft bushing is damaged / worn.
o
Needle Shaft
a
2.25 Needle
s
Needle Bolt
d
Convex Piston
f
Teflon Wear Band Replace with new when servicing shock.
g
Lock Nut 20 ft-lbs (27 Nm)
Replace with new when removed.
h
Shaft Spacer
j
Spring Nut
k
Bleed Screw
l
O-Ring Replace with new when removed.
1(
O-Ring Replace with new when removed.
2)
O-Ring Replace with new when removed.
2!
Button Head Screw
2@
Sleeve
2#
Bushing
2$
Extended Loop
2%
Detent Ball
2^
Detent Spring
2&
Clicker Knob
2*
O-Ring Replace with new when removed.
2(
Reservoir Body
3)
Reservoir Piston
3!
Wear Band Replace with new when servicing shock.
3@
O-Ring Replace with new when removed.
3#
Bleed Screw
3$
End Cap / Service Port Replace service port assembly after fifth charging.
3%
Snap Ring
3^
Clicker Stud
3&
Clicker Piston
3*
Clicker Bolt
3(
Slotted Spring Retainer
4)
Snap Ring
4!
Washer
