9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
IGNITION COIL PACK CONNECTORS
1. Connect the MAG coil connector (white connector)
q
from the main harness to the coil pack. Connect the PTO coil
connector (blue connector)
w
from the main harness to the coil pack.
BATTERY / ELECTRICAL
