Polaroid SprintScan SS35

110
Slide Scanner Repair Manual Diagnostics and Troubleshooting
Figure 5-3. Calibration error flow diagram
No Calibration
Error
Slide Scanner
OK
Rescan
Replace
Main Controller
PC Board
Calibration
Error
Replace
Sensor (CCD)
Assembly
Re-adjust
Focus and Magnification
(See Section 3 of Repair Manual)
Run
LabVIEW Test
A
Bad Pixel
Error
