Slide Scanner Repair Manual Parts Replacement
Installation
1. Install the power supply PC board.
2. Install and tighten the four (4) screws that secures the power supply PC to the bottom case.
3. Connect all electrical connectors/cables of the power supply PC board .
Electrical cables to be reconnected:
• Green ground spade lug
• AC input cable
• AC inverter power cable
• Main controller PC board (J5 & J6)
4. Install the power supply shield.
5. Install the chassis assembly.
6. Install the main controller PC board.
7. Install the top housing.
