Slide Scanner Repair Manual Parts Replacement
Installation
1. Reconnect the four (4) electrical cables from the scanning lamp (Blue - BL, White - WH,
Red - RE, Orange - OR) to the applicables pins on the AC inverter PC board.
2. Install the AC inverter PC board.
3. Install and tighten the screw that secures the AC inverter PC board to the bottom case.
4. Reconnect the AC inverter cable to power supply PC board.
5. Install the top housing.
