Slide Scanner Repair Manual Diagnostics and Troubleshooting
Error Messages
The scanner is capable of generating four (4) types of error messages:
• Diagnostic (Digital Hardware)
• Operational
• Calibration
• Miscellaneous
The generated error messages are displayed cumulatively in hexadecimal by the host computer.
They are grouped as four (4) consecutive hexadecimal bytes in least significant byte (LSB) to
most significant byte (MSB). Refer to conversion Table 5-1 to translate displayed hexadecimal
error messages. The example error message shows a multiple error.
Example Error Message: Table 5-1. Conversion Table
Binary Hexadecimal
0000 0
0001 1
0010 2
0011 3
0100 4
0101 5
0110 6
0111 7
1000 8
1001 9
1010 A
1011 B
1100 C
1101 D
1110 E
1111 F
Calibration
Error
00 02 40 00
Operation
Error
MSB - - - - - - - - - - - - - - - - LSB
Miscellaneous
Error
Diagnostic
Error
