Slide Scanner Repair Manual Calibration and Adjustments
Required Tools and Equipment
1. Tools:
• Standard tool kit
• 1.5mm and 2mm hex Allen wrench
• Lens adjustment tool
• Plastic tweaking tool
• Dental pick or equivalent
2. Safety Equipment:
• Anti-static mat and wrist strap
• Safety glasses
3. Cleaning Equipment:
• Lens paper and lens cleaning fluid
• Cleaning brush
• Can of compressed air
• Cotton gloves or finger cots
• Cleaning instructions
4. Test Equipment:
• LabVIEW Runtime Test Software w/Concept VI License for Mac
• Voltmeter (Fluke #8026B or equivalent)
• Dual Trace Oscilloscope (20 Mhz with external sync and delay time base)
• SCSI terminator, 50-pin
• SCSI cable
• Trigger cable
• AC power cord
5. Test Targets:
• Color (CT) target (P/N 1E4316A)
• Geometric (GMT) target (P/N 1E6682A)
• Focus/Magnification target (P/N 1E6694A)
• Multi-Color streak target
• Magenta stripe target
• Test pattern
• Q60 35MM target
Optional, not required for LabVIEW
