Polaroid SprintScan SS35 User Manual

77
Slide Scanner Repair Manual Parts Replacement
Installation
1. Install the front door latch making sure it is properly seated in the top housing (Figure 4-3).
2. Install the top housing making sure that the tabs on the base of the upper housing align with the
slots at the front and rear of the bottom case. Snap the top housing into the bottom case.
3. Install and tighten the four (4) screws that secures the top housing (Figure 4-3) to the bottom
case.
4. Install the scanning lamp.
5. Install the front door (Figure 4-4).
Figure 4-4. Top housing and front door secured to bottom case
Front Door
Top Housing
Bottom Case
