101
Slide Scanner Repair Manual Diagnostics and Troubleshooting
Operational
The two (2) hexadecimal digits assigned to operational type errors indicate a failure in the
scanning process. Refer to Table 5-3 for a list and definition of all operational type error codes.
Table 5-3. Operational Error Messages
Hex Code Error Definition Probable Cause Action
00 00 01 00 FEEPROM checksum is New version of Reboot slide scanner.
corrupted. firmware installed. The error should clear.
Note: Most of the data Defective FEEPROM. Replace main PC
in firmware is controller board.
automatically reset
to factory defaults
when this error occurs.
Includes CCD
configuration.
00 00 02 00 Transporter timed out Transporter operation Replace transporter
while returning to its erratic or jams. assembly.
home position.
Transporter photo- Re-align transporter
sensor tab alignment photo-sensor tab.
incorrect. Refer to alignment
procedure in Section 3
of this Repair Manual.
Note: If all else fails, replace
main controller PC
board.
00 00 04 00 Line sync timed out during Missing line sync bit. Check LSYNC output signal
calibration or diagnostics. on pin 2 of connector J8.
If line sync bit is missing,
replace main controller PC
board.
Note: Test point LSYNC on
SS35 PLUS.
* SprintScan PLUS only.
* * Not Used in SprintScan PLUS.
*
