22
Slide Scanner Repair Manual Scanner Overview
Operation
The following operational flow diagrams (Figures 1-3 through 1-6) briefly describe how to setup
the slide scanners, install and start their software, assign their SCSI ID value, and scan a
mounted or unmounted 35 mm transparency using the SprintScan 35 application software.
Each operational flow diagram is intended to be used only as a Quick reference for the repair
person. For detailed information pertaining to the information in each operational flow diagram
(setting up the slide scanner, installing and starting its software, assigning its SCSI ID and
checking the SCSI connection, and scanning a 35 mm transparency using SprintScan, refer to the
applicable slide scanner User's Guide.
Setting Up the Slide Scanner
Figure 1-3. Setting up slide scanner
Install
Adaptec SCSI
Adapter to Host
Set to 6
Assign /Select
SCSI ID
Connect
SCSI Terminator
to Scanner
Connect
Scanner to Host
A
Turn On Scanner,
then Host
Turn On
SCSI Terminator
Switch
SS35/SS35 ES
SS35 PLUS
1
Notes: 1 - If host already has a SCSI adapter, add slide scanner to SCSI chain.
2 - If slide scanner is only, or last device, in SCSI chain.
DO NOT CONNECT SS35 ES SLIDE SCANNER TO SCSI CHAINS
WITH HARD DRIVES (Applies to PC, only and slide scanners with
firmware version 1.02 or lower).
2
2
Windows Version
Mac Version
To Next Page
