Slide Scanner Repair Manual Diagnostics and Troubleshooting
146
CCD Configuration
At present, this feature is not being used.
When this feature is implemented, a bulletin will be generated detailing its options and use.
Determining CCD Configuration Using Scanner Tester
Always select Do not Update.
Currently no configuration is written into the slide scanner, but the slide scanner’s
configuration code will be read and displayed in the CCD Config. Data array display
located in the lower right hand corner of the Scanner Tester front panel and will be written
into the test report. Check the code against the tabulation label on the bottom of the
slide scanner housing and, if possible, the tabulation label on the CCD sensor PC board.
