Polaroid SprintScan SS35

Slide Scanner Repair Manual Scanner Overview
19
Rear
Front
SCSI Receptacles
(Top and Bottom)
Power On/Off
(1/0) Switch
SCSI
ID Selector
Fuse
Receptacle
Power
Receptacle
Power
LED Indicator
Ready
LED Indicator
Top
Access Slot
Side
Access Slot
Release
Button
SS35/SS35 ES
SS35 PLUS
SCSI Receptacles
(Top and Bottom)
SCSI
Terminator Switch
Power
Receptacle
Power On/Off
(1/0) Switch
Figure 1-2. Slide scanner features
Polaroid SprintScan 35
SCSI
ID Selector
Fan
Fan
