68
Slide Scanner Repair Manual Calibration and Adjustments
Figure 3-14. Lens block assembly adjustment
SS35/SS35 ES
SS35 PLUS
Optical Block
Screw
Remove Controller Board
Lens Block Screws
Optical Block
Screw
Remove Controller Board
Lens Block Screws
Note: For SS35 ES from serial no.
B6xxxxxxE and SS35 PLUS
Note: For original SS35 and SS35 ES
up to serial no. B6xxxxxxD.
