Technical Specification
Analysis Method
Non-dispersive infrared, configured as an absolute absorptiometer with
microprocessor control of linearization
CO
2
Measurement
Ranges
0-1000 ppm (µmol mol
-1
)
0-2000 ppm (µmol mol
-1
)
0-5000 ppm (µmol mol
-1
)
0-10000 ppm (µmol mol
-1
)
0-20000 ppm (µmol mol
-1
)
0-30000 ppm (µmol mol
-1
)
0-50000 ppm (µmol mol
-1
)
0-100000 ppm (µmol mol
-1
)
Readings are automatically corrected for temperature and pressure.
Accuracy
< 1% of span concentration over the calibrated range but limited by the
accuracy of the calibration mixture.
Linearity
< 1% throughout the range
Stability
Auto-zero at regular intervals corrects for sample cell contamination,
source and detector ageing and changes in electronics.
Warm-up Time
Approximately 15 minutes
Sampling Rate
10 Hz. Sample data is averaged and output every 1.0 seconds.
Sampling Pump
Integral, 5V rotary vane air sampling pump
Gas Flow Rate
100-500 cc/min (280-340 cc/min is optimal). An internal, electronic flow
sensor monitors flow rate.
Terminal Block
External 10 pin terminal connector for; +5V, Ground, Analog input, Analog
output, and alarm relays.
Analog Input
0-1.0V
Analog Output
0-2.5V (CO
2
range selectable)
Alarm
2 relay contacts (Alarm1 and Alarm2), Visual and Audible alarm/warnings.
Communications
USB(USB Mini-B) and Optional Wi-Fi
Air Filter
Internal hydrophobic filter is used to protect analyzer from water.
CO
2
Control
High and low user set points
Data Storage (USB)
USB Flash Drive for data storage
Display
2.7” electronic paper touch display with 264 x 176 pixel resolution
Power Switch
Illuminated On/Off power switch
Internal Battery
7.2 Volt - 8.7Ah (63Whr) Li-Ion battery providing up to 16 hours continuous
operation. If external sensors/accessories are used with the EGM-5 it will
reduce the operation time.
Power Requirements
12 VDC, 3.0A or AC Adapter (included) 100-240 VAC, 50-60 Hz, 1.0A
Power Consumption
Charging Battery: 30W (12V @ 2.5A)
Warm up: 12W (12V @ 1.0A)
Normal operation: 6W (12V @ 0.5A)
Gas Connections
2 Quick disconnect style fittings (inlet and exhaust) for use with 1/8” (.125”)
ID tubing
Operating Temperature
0-50
o
C, non-condensing. External filtration may be required in dirty
environments.
Enclosure
Durable Cast-Urethane and aluminum, IP43 enclosure
Dimensions
215 cm W x 200 cm H 120 cm W (Enclosure only)
Weight
1.6 kg
