EGM-5 Operation Manual V. 1.04 98 support@ppsystems.com
EGM-5 Auto Strings
Auto Strings are text strings that are sent by the EGM-5 automatically under certain states and conditions
EGM-5 Auto Command Set
String
Type
Description
*
Auto
“*” String (Power Reset)
Sent immediately after the EGM-5 is turned on or reset.
Example:
*<CR>
E
Auto
“E” String (Error Status)
Transmitted whenever an error is detected. The E string contains an Error Code that
indicates the problem. See Error Messages on page 117 for more details.
Example:
E,11<CR>
In this example, 11 is the code for the Low CO
2
Alarm.
M
Auto
“M” String (Measurements)
The M string is sent on a fixed interval. The interval and the string format may be
modified. When the interval is set to 0 the M string stops sending automatically, but
can be manually polled by sending the “M” command.
Example:
M3, 03/06/15, 09:32:15, 1, 0003, 1094, 1004.2, 327, 0.0, 00.0, 20.41, 00<CR>
In this example, the Measure Format setting had been set to 3. See
Measure Format
Settings Table on page 93 for more details.
V
Auto
“V” String (Versions)
This is sent once right after the EGM-5 is powered on, or if the system is reset. The V
string contains the serial numbers and software versions of the EGM-5 controller, the
IRGA and the Display.
Example:
V,EGM500007,01.02,IRGA00001,01.01<CR>
In this example,
EGM500007 is the EGM-5 serial number
01.02 is the EGM-5 firmware version number
IRGA00001 is the IRGA serial number
01.01 is the IRGA firmware version number
