Getting Familiar with the EGM-5
Touch Display
The EGM-5 features a 2.7” a-Si, active matrix TFT, Electronic Paper Display (EPD) touch panel. The
panel has such high resolution (117 dpi) that it is able to easily display fine patterns with excellent
readability under sunlight conditions. Due to its bi-stable nature, the EPD panel requires very little power
to update and needs no power to maintain an image.
Features
• a-Si TFT active matrix Electronic Paper Display (EPD)
• Resolution: 264 x 176 pixel
• Ultra-low power consumption
• Super Wide Viewing Angle - near 180°
• Slim & lightweight enclosure
• SPI interface
• RoHS compliant
CO
2
scrubber
status and
manual Zero
button
Touch display
Polyurethane
shock-absorbing
base and battery
compartment
Adjustable Carry
Handle
Flashing Heart
(Power Status)
and battery
capacity
